MAIN SPECIFICATIONS

• Type of hoods: Free standing island hood
• Output air extraction (m3/h): 740
• Width (cm): 90

CONTROL PANEL

• Type of control: Electronic

LIGHTING

• Number of lights: 4
• Light position: Front;Rear
• Type of bulb: Halogen
• Lighting power (W): 80

PERFORMANCE

• Number of speed positions: 3
• Acoustic power level (recycling) (dBA): 61
• Max recycling air extraction (m3/h): 430
• Boost position output recirculating (m3/h): 500
• Boost position air extraction (m3/h): 632
• Minimum evacuation sound level (dBA): 66
• Max evacuation sound level (dBA): 75

FILTERING

• Number of filters: 2

Accessories:

• Charcoal filter

DIMENSIONS

• Height of product without chimmey (mm): 55
• Dimensions of product HxWxD (mm) : H55 x W900 x D600 (without chimney)
• Height of chimmey min/max (mm): 600 - 1100
• Built in dimensions HxWxD(mm): 600-1100 X 900 X 600
• Dimensions of the packed product HxWxD (mm): 400 X 955 X 660
• Gross weight (kg): 37.5
• Net weight (kg): 31.5

CONNECTIONS

• Voltage (V): 230-240
• Frequency (Hz): 50
• Current (A): 10
• Connection rating (W): 350
